RGV Performance
DS18 Car Audio Full Range 4 Channel 1200W Amplifier Class A/B Black SXE-1200.4-BK
DS18 Car Audio Full Range 4 Channel 1200W Amplifier Class A/B Black SXE-1200.4-BK
Regular price
$140.99 USD
Regular price
$144.95 USD
Sale price
$140.99 USD
Unit price
per
Couldn't load pickup availability
DS18 Car Audio Full Range 4 Channel 1200W Amplifier Class A/B Black SXE-1200.4-BK
This listing includes :
(1) Black Full Range 4 Channel 1200W Amplifier SXE-1200.4-BK
DS18’s SXE series of amps was designed for users looking for an extreme increase to the quality of music reproduced by their vehicle. The SXE-1200.4 guarantees your sound system’s speakers perform at their peaks on every use.
The SXE series of amplifier gives users the ability to tailor the audio reproduced by their vehicle to their personal listening preferences through the use of it’s fully variable crossover, adjustable gain input sensitivity, and multi-channel amplifier design: everything you need to take control of your listening experience.
As a Class A/B amplifier, the SXE series uses power transformers significantly smaller than your average amplifier, making it the perfect size for any vehicle’s custom build: but, what it lacks in size it makes up for in power. The SXE-1200.4 has a power output of 200W x 2 CH bridged at 4-ohms, 100W x 4 CH at 2-ohms, 60W x 4 CH at 4-ohms: perfect power settings to supercharge any custom build.
HIGHLIGHTS :
- Compact size for easy installation anywhere
- Stable Two or Four Layer Traced PCB Design
- Audio Precision Quality Control Verification
- Full Adjustable HP/LP @ 12dB/oct Crossover
- Various Forms of Electronic Protection
SPECIFICATIONS -
POWER :
-Total Watts (Peak)1200W
-RMS Power @ 4 ohms4 x 60W
-RMS Power @ 2 ohms4 x 100W
-RMS Power @ 4 ohms Bridge 2 x 200W
AUDIO :
-Frequency Response10Hz-20KHz
-Signal to Noise Ratio90dB
-Efficiency @ 4 ohms64%
-Damping Factor170
-Input Impedance20kΩ
-Channel Separation45dB
-Total Harmonic Distortion (THD)0.05%
-Low Level Input Range200mV-5V
-Selectable X-OverHPF/FULL/LPF
-X-Over Filter Range40Hz-2KHz
FEATURES :
-Amplifier ClassAnalog (AB)
-Amplifier TypeStereo Full Range
-Number of Channels4
-Minimum Impedance2 Ohms Stereo / 4 Ohms Bridge
-Led IndicatorPower/Protect/Clip
-Power Input Terminal Size 4Ga
-Fuse Size2 x 25A (50A)
-Cooling FanYes
-Thermal ProtectionYes (80℃)
-Over-Load ProtectionYes
-DC Output ProtectionYes
-Short Circuit Output ProtectionYes
-Voltage Input ProtectionYes (16.5v)
-Clipping ProtectionYes
-Body Color / FinishRed / Black Brushed Aluminum
MEASUREMENT :
-Overall Length9.8" / 249.3mm
-Overall Wide5.5" / 140mm
-Overall Height1.8" / 48mm
-Heatsink Length8.34" / 212mm
-Gross Single Unit Weight 1.76KG
This listing includes :
(1) Black Full Range 4 Channel 1200W Amplifier SXE-1200.4-BK
DS18’s SXE series of amps was designed for users looking for an extreme increase to the quality of music reproduced by their vehicle. The SXE-1200.4 guarantees your sound system’s speakers perform at their peaks on every use.
The SXE series of amplifier gives users the ability to tailor the audio reproduced by their vehicle to their personal listening preferences through the use of it’s fully variable crossover, adjustable gain input sensitivity, and multi-channel amplifier design: everything you need to take control of your listening experience.
As a Class A/B amplifier, the SXE series uses power transformers significantly smaller than your average amplifier, making it the perfect size for any vehicle’s custom build: but, what it lacks in size it makes up for in power. The SXE-1200.4 has a power output of 200W x 2 CH bridged at 4-ohms, 100W x 4 CH at 2-ohms, 60W x 4 CH at 4-ohms: perfect power settings to supercharge any custom build.
HIGHLIGHTS :
- Compact size for easy installation anywhere
- Stable Two or Four Layer Traced PCB Design
- Audio Precision Quality Control Verification
- Full Adjustable HP/LP @ 12dB/oct Crossover
- Various Forms of Electronic Protection
SPECIFICATIONS -
POWER :
-Total Watts (Peak)1200W
-RMS Power @ 4 ohms4 x 60W
-RMS Power @ 2 ohms4 x 100W
-RMS Power @ 4 ohms Bridge 2 x 200W
AUDIO :
-Frequency Response10Hz-20KHz
-Signal to Noise Ratio90dB
-Efficiency @ 4 ohms64%
-Damping Factor170
-Input Impedance20kΩ
-Channel Separation45dB
-Total Harmonic Distortion (THD)0.05%
-Low Level Input Range200mV-5V
-Selectable X-OverHPF/FULL/LPF
-X-Over Filter Range40Hz-2KHz
FEATURES :
-Amplifier ClassAnalog (AB)
-Amplifier TypeStereo Full Range
-Number of Channels4
-Minimum Impedance2 Ohms Stereo / 4 Ohms Bridge
-Led IndicatorPower/Protect/Clip
-Power Input Terminal Size 4Ga
-Fuse Size2 x 25A (50A)
-Cooling FanYes
-Thermal ProtectionYes (80℃)
-Over-Load ProtectionYes
-DC Output ProtectionYes
-Short Circuit Output ProtectionYes
-Voltage Input ProtectionYes (16.5v)
-Clipping ProtectionYes
-Body Color / FinishRed / Black Brushed Aluminum
MEASUREMENT :
-Overall Length9.8" / 249.3mm
-Overall Wide5.5" / 140mm
-Overall Height1.8" / 48mm
-Heatsink Length8.34" / 212mm
-Gross Single Unit Weight 1.76KG
